Room Partition Wall

Room Partition Wall Materials Soundproof Sliding Room Partitions

SKU: Room Partition Wall Category:
General Details

Room Partition Wall

Our room partition wall is a movable soundproof room partition system which forms a removable wall. The sliding room partitions are often used to temporarily divide a big room into several small rooms. Unlike other room partition materials, our room partition wall has excellent soundproofing performance and they are hanging on an overhead track system.

Technical Specification

Panel Configuration – The room partition wall panels are customized to meet specific requirements. Each room partition board thickness is 100mm and max width is 1200mm. Each single room partition wall panel is welded with a welded aluminum frame and 9mm MDF is mounted on both sides of the outer surface. The internal structure is made of steel mechanism, which combines excellent performance at the top and bottom of the telescopic sound seal. Internal space is filled with less than 64 kg/m3 glass wool.

Overhead track system – specific aluminum alloy rails to meet the necessary stacking requirements. The intersection design should prevent the track wheel from falling into the track groove. Heavy-duty multi-way roller enables easy movement of the sliding partitions for rooms through the ceiling track.

The panel of room partition wall has a unique fast seal winding mechanism and a solid vertical seal edge profile to ensure that all panels fit perfectly.

Sound Seal System – Built-in excellent retractable top and bottom seals are anodized by extruded aluminum channels, rubber sealed, and operated by a handle with a cap lock system with spring-loaded telescopic rods. The vertical seal of each panel is made of thick and tongue-type extruded aluminum laminated with rubber seal.

Room Partition Wall Materials Soundproof Sliding Room Partitions

Top and bottom seals do not collected to the ceiling track and floor during panel’s movement. When the sound seals are combined, the large room partitions panel is placed in a stable position, and the top and bottom seals are compressed on the rails and floors by tight acoustic seals, including adjustable telescopic panels.

Acoustic RatingAcoustic screens with high acoustic performance should provide an average sound attenuation of 45Db to 50DB.

Weight – The weight of each room partition walls panel should be an average of 40 kg/m2, depending on the panel size.

Panel surface – By default it’s 9mm MDF board. However, it can be adapted to any decorative design, such as wood veneer, fabric, etc.

Applications and operations – The soundproof and decorative room partitions consist of a series of single flat wall panels that are manually operated and allow stacking flexibility of the center or remote side.
